DESCRIPTION:

Toroidal Split Core Current Transformer leads with shielding wire elicited, output end can be DC or terminal. The Insulating medium is epoxy resin. The Application of this is used in electronic energy meter, instrument, position sensor, current sensor, PDU, switch power, induction cooker. The maximum current that can be used in this current transformer is 120A and the rated output current is 40mA.

Features:

• Phase: single
• Usage: measurement
• Insulating medium: epoxy resin

Specification:

• Rated input current : 0~120A
• Coil Ratio:3000:1
• Rated output Current: 40mA
• Load Resistance: 10ohm
• Output voltage:400mV
• Accuracy:0.5%
• Phase Component: -0.15%
• Max Current: 120A
